Modular Operating Room (Modular OT) is a pre-engineered, factory-prefabricated integrated sterile surgical space, replacing traditional on-site wet construction. All wall, ceiling, door, cabinet and purification components are standardized modular modules produced in factory, then quickly assembled on-site with aluminum sanitary extrusion profiles, cutting construction period by over 50% and drastically reducing on-site dust and pollution risks.

1. Class100 Positive Standard Modular OT: General surgery, orthopedics, ophthalmology, plastic surgery (ISO5 laminar flow above operating table)
2. Negative Pressure Modular OT: Infectious disease, respiratory pathogen surgery, prevents pathogen outward leakage
3. Radiation Protection Modular OT (Interventional OT): Built-in lead-lined wall & radiation-proof sliding hermetic door for CT/DSA cardiovascular & neuro interventional surgery
4. Digital Intelligent Modular OT: Integrated surgical imaging, remote teaching, whole-room linkage intelligent control

1. Modular Enclosure Main Material & Aluminum Installation Accessories

1.1 Wall & Ceiling Sandwich Panel (Handmade Medical Special Grade)

• Facer: 0.8–1.2mm antibacterial PPGI / SUS304 stainless steel (SUS316L for heavy disinfection vaccine OT)
• Core options: A1 fireproof rockwool / moisture-proof MGO magnesium oxide core (50/75/100mm thickness standard)
• Feature: Four-side aluminum reinforced frame, hidden tongue-and-groove interlock with EPDM airtight seal, pre-cut reserved openings for LAF ceiling, gas cabinets, observation windows, return air grilles to avoid on-site dust cutting

1.2 Complete Sanitary Aluminum Extrusion Accessories

• R35/R50 inner rounded coving (wall-ceiling, wall-floor transition, eliminate right-angle dead corners, mandatory GMP design)
• H-type wall joint, T-type three-way connector, U edge wrapping channel
• Ground integrated skirting, door/window surrounding frame, ceiling FFU hanging keel
• All profiles with built-in EPDM sealing grooves for continuous airtight splicing, maintain stable room differential pressure

1.3 Seamless Medical Flooring

2. Laminar Airflow Purification HVAC Core System (Class100 Standard)

2.1 Terminal LAF Laminar Flow Ceiling

• Full SUS304 stainless steel frame, built-in H14 gel-seal mini-pleat HEPA filter (99.995% @0.3μm, 100% PAO integrity tested)
• Vertical unidirectional downward laminar air velocity 0.3–0.45m/s directly above surgical table, forms Class100 ultra-clean core zone
• Size customizable: 2400×1800mm / 3000×2400mm according to OT area
• Reserved central hole for surgical shadowless lamp suspension pendant installation

2.2 AHU Air Handling Unit & Multi-Stage Filtration

1. Primary stage: G4 washable pre-filter
2. Medium stage: F8 pocket filter
3. Terminal stage: H14 HEPA laminar ceiling filter

• Constant temp range: 20–26℃; constant humidity: 40–60% RH
• Positive pressure standard OT: +10 ~ +15Pa higher than outer buffer corridor; negative infectious OT: -8 ~ -12Pa relative to outside

2.3 Return Air System

3. Full Series Hermetic Door System for Modular OT

1. Manual Unequal Double Hermetic Door: Main daily personnel passage (900+300 split), large leaf for staff, small auxiliary leaf for surgical trolleys
2. Automatic Sliding Hermetic Door: Touch-free radar/foot sensor trigger, inward cam sinking full four-side airtight seal, high-traffic main entrance
3. Radiation Protection Automatic Sliding Hermetic Door: Lead-lined door leaf 1–5mmpb lead equivalent, matched interventional radiology modular OT
4. Pass Box (Transfer Window): Stainless steel interlock pass box with UV lamp, for sterile instrument/material transfer between clean/dirty zones without opening main door

   All doors equipped with auto drop-down bottom silicone seal, full perimeter EPDM compression gasket to stabilize room pressure gradient.

4. Integrated Stainless Steel Medical Built-In Cabinets

1. Anesthesia Cabinet: Central medical gas terminal panel, oxygen, vacuum, nitrous oxide, AGSS anesthetic waste gas recovery interfaces
2. Instrument Cabinet: Multi-layer sealed storage for sterile surgical tools
3. Medicine & Insulation Cabinet: Constant temperature medical storage cabinet, cold storage drug compartment
4. Wall-mounted X-ray film viewer, integrated writing whiteboard, multi-group medical power socket bank

5. Ceiling Suspension Medical Pendant System

• Gas outlets: O₂, vacuum, N₂O, compressed air, AGSS waste anesthetic gas scavenging
• Multi-group medical grade power sockets, data communication interface, infusion hook, instrument tray
• Rotatable 340° horizontal angle, height adjustable, bearing surgical monitor, anesthesia machine, electrocoagulator equipment

6. Intelligent PLC Central Control System

• Real-time display: room temp, humidity, differential pressure, laminar wind speed, filter clogging alarm
• Independent control: shadowless lamp brightness, peripheral purification lighting, UV timing disinfection, AHU fan speed
• Fault self-diagnosis, running data record, support GMP IQ/OQ validation data export
• Optional linkage: door interlock signal, remote background monitoring, nurse station alarm notification

7. Supporting Auxiliary Modular Facilities

1. Stainless steel surgical scrub sink (3/4/6 station hands-free induction water tap, installed in pre-operation buffer room)
2. Clean garment cabinet (dynamic LAF laminar flow sterile gown storage for surgical staff changing area)
3. Air shower (auto sliding door air shower for personnel entry dust removal before OT buffer zone)
